FT232H High Speed Multifunction USB Communication Module USB To SPI/I2C/UART Serial Adapter Board For MCU Program Download And Data Transmission

FT232H High Speed Multifunction USB Interface Module

📌 Product Overview FT232H is a single-channel USB2.0 high-speed (480Mb/s) to multi-interface conversion module based on FT232H chip. It can be configured to multiple industry-standard serial and parallel interfaces, including UART, SPI, I2C, JTAG, FIFO and Bit-Bang mode. The chip handles the entire USB protocol internally, no dedicated USB firmware programming required. It supports FTDI royalty-free VCP and D2XX drivers, greatly simplifying PC-side development. This module leads out abundant GPIO and analog acquisition pins, widely used for USB to serial debugging, SPI/I2C host communication, JTAG download, data high-speed transmission and embedded secondary development projects. ✨ Core Features

• USB2.0 Hi-Speed 480Mb/s, compatible with Full Speed 12Mb/s
• Multi-protocol synchronous serial engine (MPSSE), supports USB to JTAG, I2C, SPI master, Bit-Bang
• UART baud rate up to 12M baud
• Asynchronous 245 FIFO: up to 8MByte/s; synchronous 245 parallel FIFO up to 40MByte/s
• Built-in FTDI VCP & D2XX driver, no custom USB firmware needed
• Adjustable receive buffer timeout
• Rich pinout: GPIO, analog input, +5V, +3.3V, GND power pins
• Onboard power circuit, stable power output for external small devices

📋 Product Parameters

Item	Specification
Main Chip	FT232H
USB Standard	USB 2.0 High Speed 480Mb/s
Interface Mode	UART, SPI, I2C, JTAG, FIFO, Bit-Bang
UART Max Rate	12M baud
Synchronous FIFO Speed	40 MByte/s
Asynchronous FIFO Speed	8 MByte/s
Module Dimension	57.7 X 28.8 X 1.6mm
Net Weight	6.7g
Working Temperature	-40℃ ~ +85℃
Brand	LIZAO
Type	USB Interface Converter Module

📐 Dimension Info

• Module size: 57.7 X 28.8 mm, Net weight:6.7g

⚠ Important Notes

• This module is powered by USB port, avoid overloading the power pins.
• Different working modes need to be configured via driver software on PC side.
• Do not input voltage higher than 3.3V into IO pins to prevent chip damage.
• Minor PCB layout changes may exist between batches, please refer to the real product.

🛠 Application Scenarios

• USB to UART / RS232 / RS422 / RS485 serial adapter
• USB to SPI / I2C host communication debugger
• JTAG interface download and debugging
• High-speed USB FIFO data transmission
• Bit-Bang GPIO control, analog signal acquisition
• Embedded development, test measurement and automation control
